DIN Rail Mount 8 Amp Solid State Relay SSR Module, in 4~32VDC, Out 100~240VAC. (2 Channels)
4.0 (44 items)
Limited Time SaleUS$15.00 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 221103243 | Release Date | 2026/05/03 | List Price | US$10.00 | Model Number | 221103243 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The product datasheet: https://images-na.ssl-images-amazon.com/images/I/918GgW8v9PL.pdfFeature: 1, MOC3043 Phototriac and BTA12-600B triac (the heatsink is electrically insulated). 2, Input Action Voltage DC 3 to 32V. LED indication for each channel. Anti-reverse protection diode. 3, Output Load Voltage range AC 100 to 240V (50/60Hz). Maximum on-state average current: 8 Amp, maximum on-state current 12 Amp (<10 seconds). Isolation: Phototriac. Zero cross: Yes. 4, Terminal Block: Wire range: 24 ~ 12 AWG / 2.5mm square. Strip length: 7mm. Screws - M2.5, steel, Cr3+ Zn plated. Pin header and Cage - Brass. 5, DIN rail mount, Taiwan DINKLE fireproof nylon material DIN rail mount carrier (not China low quality carrier), can support width 35mm / 32mm / 15mm rail. FR-4 fiber glass PCB, dual copper layers. Characteristic Parameters: Input Signal Control Terminal: Action Voltage: 3 ~ 32 VDC. Current: 6mA at 5VDC, 8mA at 12VDC, 11mA at 24VDC, 13mA at 32VDC. Turn off voltage: 0 ~ 0.8 VDC. In-Out isolation surge voltage: 7500V. Output Terminal: Load voltage range: 100 to 240 VAC (50/60Hz). Max. on-state average current: 8 Amp. Max. on-state current: 12 Amp (<10 seconds). Non repetitive surge peak on-state current: 120 Amp (<20mS). Max. on-state voltage drop: 1.5V. Max. off-state current: <2mA / at 220VAC. Off-state max. allow voltage: 400V. Isolation: Phototriac. Zero cross: Yes. Load type: General purpose. Terminal block specifications: Wire range: 24 ~ 12 AWG / 2.5mm square. Strip length: 7mm. Screws - M2.5, steel, Cr3+ Zn plated. Pin header and Cage - Brass.
- MOC3043 Phototriac and BTA12-600B triac (the heatsink is electrically insulated).
- Input Action Voltage DC 3 to 32V. LED indication for each channel. Anti-reverse protection diode.
- Output Load Voltage range AC 100 to 240V (50/60Hz). Maximum on-state average current: 8 Amp, maximum on-state current 12 Amp (< 10 seconds). Isolation: Phototriac. Zero cross: Yes.
- Terminal Block: Wire range: 24 ~ 12 AWG / 2.5mm square. Strip length: 7mm. Screws - M2.5, steel, Cr3+ Zn plated. Pin header and Cage - Brass.
- DIN rail mount, Taiwan DINKLE fireproof nylon material DIN rail mount carrier (not China low quality carrier), can support width 35mm / 32mm / 15mm rail. FR-4 fiber glass PCB, dual copper layers.
| Model | MD-D1303T series |
|---|---|
| Brand Name | CZH-LABS |
| Part Number | MD-D1303T series |
| Coil Voltage | 12 Volts |
| Contact Type | Normally Open |
| Manufacturer | Electronics-Salon |
| Mounting Type | DIN Rail Mount |
| Connector Type | Screw |
| Current Rating | 8 Amps |
| Operation Mode | Automatic |
| Specification Met | Din |
| Contact Current Rating | 12 Amps |
| Maximum Switching Current | 12 Amps |
| Maximum Switching Voltage | 240 Volts |
